Applications & Features
- Temperature range from -40 Deg F to 1200 Deg F
- Higher temperature applications available
- Design loads based on a safety factor of 5
- A36 steel construction
- See technical specification RHS-750

-Test results available upon request
- Steel finish available in galvanized finish or painted
- Increased loading capability available. Contact Rilco for more information
- Support constructed in accordance with ASME B31.1, B31.3, and MSS-SP58 - A307 or A193 B7 plated bolts/studs

Ordering Instructions - Please Specify:
- Model Number
- Nominal Pipe Size
- Insulation Thickness
- E
- Support Length (F)
- Vertical Load
- Movements
